Our years of plastic engineering knowledge and tooling experience combined with the latest technological advancements provide you with the most cost-effective and efficient service processes and solutions. Our Plastic Engineering & Technical Services team is a recognized leader in providing analytical services in mold-filling, mold cooling, shrink & warp analysis, gas assist analysis, injection compression, co-injection and more. To achieve the most optimal manufacturing solution, we recommend the moldflow simulation process for multiple gate parts, family tooling, multicavity and imbalanced molds. Save time and money by conducting a moldflow analysis during the design process.
FLOW
Visualize 3D filling patterns
Predict weld lines and air traps
Predict the injection pressure
Evaluate pressure distribution
Evaluate temperature distribution
Evaluate shear rate, velocity and stress
Optimize gate location, gate size and process conditions
PACK
Visualize volumetric shrinkage areas
Evaluate the clamping force
Evaluate pressure distribution
Evaluate temperature distribution
Evaluate density and part weight
Optimize gate freeze time
Optimize packing time, packing pressure, VP switch, etc.
COOL
Visualize 3D temperature distribution
Predict areas of hot spots
Evaluate cooling efficiency
Determine required cycle time
Minimize cooling imbalance
Generate moldbase with complex cooling channels automatically
WARP
Predict part shape for cavities
Evaluate volumetric shrinkage effect
Evaluate thermally induced residual stress
Determine the linear shrinkage ratio
Define an arbitrary reference plane
Show deformation in x, y and z direction
Export warpage shape in STL format or Moldex3D Mesh
